Automotive ECU architecture and logic
SKU# LK1800
This kit allows students to investigate Electronics Control Unit circuits using a pre-programmed micro ECU. Students start by building a fully functioning ECU with inputs, a relay and a transistor output and carry out the bulk of learning with it. Students construct a circuit around the ECU, select one of 14 programs on the ECU and work through the workbook provided. The workbook includes a number of fault finding exercises so that students can understand how faults in ECU circuits can be diagnosed and interpreted. Suitable for Level 3 students and technicians. A full workbook of exercises is provided.
Learning objectives:
- ECU operation and structure
- Logic functions
- Pulse width Modulation
- Inputs and switches
- Sensors – light, temperature, Hall effect
- Transistor and relay outputs
- Simple actuators – motors and solenoids
- Fibre optics
- Fault finding in ECU circuits
ANSI version available – order code: LK1800A
Pictures are a representation of the product and correct at the time of uploading. Occasionally there may be changes to equipment for supplier or development reasons which may not be reflected. Please check the bill of materials before purchase to confirm the contents that you will receive.
Interested in this product?
Please contact us to find out the prices in your region for this product.
Click to enquire
Automotive ECU’s Architecture and Logic (French)
REF: CP8408
Learn about ECU architecture and logic within an Automotive environment with Locktronics
Suitable for:
Automotive ECU’s Architecture and Logic (Spanish)
REF: CP8408
Learn about ECU architecture and logic within an Automotive environment with Locktronics
Suitable for:
Automotive ECU’s Architecture and Logic
REF: CP8408
Learn about ECU architecture and logic within an Automotive environment with Locktronics
