Harmonise with Technology: Cutting Edge Learning for Modern Signal Processing
Learning that is both cost and size effective for a classroom environment.
Sysblocks Overview
Together with Flowcode, Sysblocks provides a new way of teaching about signal processing for music technology, digital signal processing (DSP), communications and digital radio techniques.
Using a high speed, high power, 32bit PICmicro micro controller running at 200MHz, we are able to offer a comprehensive way of learning that is both cost and size effective for a classroom environment.
Interested in this product?
Please contact us to find out the prices in your region for this product.
Click to enquire
Programming
Sysblocks has four analogue inputs, two analogue outputs and support circuitry. The 32 bit PICmicro microcontroller is programmed by a host device which is a standard 18 series PICmicro microcontroller.
This host device takes care of non-core tasks like USB communications, LCD display, encoder and switch inputs. This architecture keeps the main 32bit device free for signal processing.
Two E-blocks ports are made available for expansion. E-block boards for Wifi, keypad, Bluetooth, CAN, Zigbee and many other functions are available, along with a Grove connector, giving huge flexibility.
Connection
The analogue input signals are buffered and level shifted to half of the supply voltage – 1.65V – and then fed to the internal A to D converters of the main 32 bit PICmicro microcontroller.
A digital potentiometer allows the level of the input signals to be adjusted in software. The board is fitted with a number of switches and encoders for control purposes.
The board also has a miniature monochrome graphical display and a number of programmable LEDs including 2 x 8 LED VU meter LEDs. The board is powered from 3.3V from USB or from a plug top power supply.
Sysblocks Solutions
There are currently two solutions available in the range – the experimentation panel and the communications panel.Â
There are however 3 full curriculum covered across these two solutions:
- Music with microcontrollers
- Systems, Signals, DSP and FFTÂ
- Communications and digital radio techniquesÂ
Â
Interested in this product?
Please contact us to find out the prices in your region for this product.
Click to enquire
Sysblocks Solutions
Communications and Digital Radio Techniques (Spanish)
REF: CP6125
Teach students about communications and digital radio techniques.
Suitable for:
Communications and Digital Radio Techniques (French)
REF: CP6125
Teach students about communications and digital radio techniques.
Suitable for:
Communications and Digital Radio Techniques
REF: CP6125
Teach students about communications and digital radio techniques.
Suitable for:
Systems, Signals, DSP and FFT (French)
REF: CP2398
The Systems, signals, DSP and FFT pack introduces students to a number concepts in digital systems.
Suitable for:
Systems, Signals, DSP and FFT (Spanish)
REF: CP2398
The Systems, signals, DSP and FFT pack introduces students to a number concepts in digital systems.
Suitable for:
Systems, Signals, DSP and FFT
REF: CP2398
The Systems, signals, DSP and FFT pack introduces students to a number concepts in digital systems.
