Automotive motors, generators & charging systems

SKU# LK2410

This kit allows students to investigate the technology behind motors and charging systems. Students start by understanding the basics of motor construction and then carry out a range of experiments that helps them understand how charging systems in vehicles work. A key theme of this pack is introducing the use of oscilloscopes and triggering oscilloscopes for simple signals: AC, DC pulse width modulated and single pulse. Suitable for Level 2 students and technicians. A full workbook of exercises is provided. This kit relies on the HP2001 DC/Brushless DC motor pair which is ordered separately.

Learning objectives:

Current – AC, DC, RMS
Motor principles
Generator principles
DC permanent magnet motor, Brushless three phase motor, Three phase generator
Half and full wave rectification
Three phase rectification
Charge systems in vehicles
DC power supplies and ripple
Zener diodes
DC motor control using Pulse Width Modulation
Oscilloscope triggering
Generating high tension
Fault finding in high tension systems

ANSI version available – order code: LK2410A

Pictures are a representation of the product and correct at the time of uploading. Occasionally there may be changes to equipment for supplier or development reasons which may not be reflected. Please check the bill of materials before purchase to confirm the contents that you will receive.
