Fault Finding in Electronic Circuits

SKU# LK3566

LK3566-75-1 WEB

This solution allows students to gain experience of fault finding on several analogue and digital systems. Students first learn how to use test equipment and test the major groups of active and passive components. Then students are given a fully working circuit so that they can understand the circuits’ function. Supervisors then insert one of a number of faults on each circuit and the student must deduce the fault through the use of the appropriate instruments. Faulty components are clearly marked underneath the carrier. Five fully tested and assembled circuits supplied.





Pictures are a representation of the product and correct at the time of uploading. Occasionally there may be changes to equipment for supplier or development reasons which may not be reflected. Please check the bill of materials before purchase to confirm the contents that you will receive.

Interested in this product?

Please contact us to find out the prices in your region for this product.

Fault Finding

REF: CP9333

Fault finding on analogue and digital systems, using test equipment to deduce faults.
